Live stream Network camera support Wireless Full HD 1080p Streaming Webcam connect to the streaming media platform

V2 Live stream Network camera which is studied, It is a one channel of 1080P embedded video and audio hardware codec. It applies H.265 and H.264 encoding standard.Hardware hevc encoders use independent SOC chips to encode and push video and audio signals, The V2 webcam encoding algorithm is used to transmit it to the network in the form of network packets. Since it only focuses on one thing, it is stable and has very low power consumption. As for video and audio quality, it mainly focuses on encoder main chip provider, please check my tweets.

    Category:

    Description

    Live stream Network camera V2 is a 1 channel of 1080P embedded video and audio Network camera. It applies H.265 and H.264 encoding standard (this standard is a digital video encoding standard made out by TTU-T and ISO). With this encoding standard,it can encode 1 channels of 1080P hevc video and stereo audio simultaneously. It is inserted with DE-interlacing scanning algorithm, which makes video quality reach the best level. Compared with the present widely used H 264 encoding algorithm, V2 Webcam can save 30-50% of transmission bandwidth and storage space at the same video quality. It has the advantages of supporting international standards, high performance, flexible configuration and strong scalability. It is suitable for radio&TV operators, telecommunications operators, governments of different levels, and school etc.

    V2 Live stream Network camera applies mini design is easy to carry, embedded OS(embedded operating system), supports 7×24 hours non-stopping work. Its platform is based on BS configuration structure; management and configuration are done by this web-page in the long –distance without being supervised by human.

    V2 Webcam h.265 and h.264 of video encoding formats are supported, Supported audio encoding formats are AAC, G.711, Support live stream protocol SRT,HTTP, HLS, RTSP, RTMP of flow push, RTMP pull flow, UDP, Multicast network protocol etc.

    Technical Features

    • Embedded hardware network camera
    • H.265,H.264 Main profile
    • Audio output format AAC(HE,LC),G.711
    • Coding Resolution: 1080P 60fps,720P(30 or 60)
    • Storage: TF card (able to download on web),video management platform,LiveX
    • Support CBR,VBR
    • Highest code rate 12Mbps
    • Shell:100mmx118mmx40mm, shell: aviation aluminum.
    • Every channel is inserted with de-interlacing scanning algorithm
    • V2 network camera can use space pre-treatment and block filtering technology for moving scenes
    • V2 webcam encoding level: 1, 2, 3, 4 and 5 (the higher the level, the larger of the code flow fluctuation ratio)
    • Timing setting: adjust X/ Y line, size, color
    • Lens optimization: AE, exposure, AWB, IDC, Fog, bad point correcting, denoise
    • It supports a variety of common platforms at home and abroad such as srt,wowza, FMS, youtube,facebook,NJ and so on

    Topology diagram of the overall scheme

    Product Advantages

    • SOC chip is even more powerful
    • Mini design is easy to carry
    • 1080P of image effect is more exquisite
    • Strong system stability
    • Low cost of maintenance
    • 7×24 non-stoping work
    • Multi-media platforms

    Software configuration picture

    Technical Specification Table

    V2 network Camera Product Parameter
    Sensing element 4 megapixel 1/3 Ultra low illumination CMOS sensor. 3.5 audio Jack
    Video parameter Coded format   H.264 Baseline profile
    H 264 Main profile
    H 264 High profile
    H 265 Main profile
    Coding resolution Main 1080P 60fps,720P(30 or 60fps)Sub 720PFrame rate 30-60 adjustable

    Multiple reference frame SmartP,DualP

    Maximum rate 12Mbps

    Rate control CBR,VBR

    Audio parameters Input interface:3.5mm Line-in( Support audio gain)

    Output interface:3.5mm Line-out(Support audio gain)

    Sampling rate 48K,44.1K,32K

    Audio bitrate 64kb/s-256kb/s

    Coded format AAC(HE,LC),G.711

    Network Parameters Lan interface 1000M RJ45

    Transport protocols  SRT,RTSP,RTMP,RTMPE,HTTP,HLS,UDP,unicast,multicast

    ONVIF positive

    File Storage Memory interface TF card (able to download on web)

    Recording format MP4,TS,FLV,MOV,MKV,AVI

    Basic parameter Power supply  DC 12V 2A

    Power dissipation <6W

    Operating temperature -20-60℃

    Size 100x65x32(mm)

    package size 100x115x40(mm)

    Net weight 0.32KG

    Gross weight 0.35

    Software function  Basic function  WEB configuration,Parameter thermal update,Firmware upgrade,Network settings,

    Password management

    Adjustments Brightness, contrast, saturation, color temperature, noise reduction, sharpening

    Special superposition Logo,Watermark, subtitle, timestamp

    User interface, remote upgrade, Andriod APP, multi-one management platform

    Application Range

    • Network video and audio broadcast based on IP protocol.
    • Suitable for all kinds of video conference software developers, system developers to do the acquisition end
    • Suitable for educational network, campus network TV broadcast, multimedia classroom broadcast, multimedia conference broadcast, and enterprises and institutions internal conference broadcast and other occasions;
    • Live broadcast of stock appraisal in securities industry and stock market and remote training within enterprises
    • Applicable to video live broadcast business of government, media industry and other portal websites
    • Suitable for remote monitoring in public places and important monitoring areas
    • Suitable for remote monitoring of military exercises and two-way audio-visual communication
