4G LTE Camera top H265 hardware video encoder E9 Camera top SDI h264 hardware video codec support Easy youtube live streaming Push and pull

E9 4G LTE Camera top H265 hardware video encoder is an advanced bonding encoder that fully developed by JLonvision, it allows to transmit max 1920* 1080P 30 FPS video over 1 aggregated Sim cards, H9 support simultaneously output to three different platform over RTMP,http,rtsp,rtp,udp etc.



E9 4G LTE Camera top H265 hardware video encoder is a 3G/4G/WIFI high-definition SDI audio and video encoder with lithium battery function.This product supports one channel HD SDI audio and video acquisition function. One channel 3.5mm independent audio interface acquisition function. Encoding output dual code stream h.265 and h.264 format, audio MP3/AAC format. The code rate can be adjusted and the picture quality can be controlled. Support HTTP/RTSP/RTP/RTMP/UDP and other protocols.Very easy to use, no hardware compatibility issues.

E9 4G LTE Camera top H265 hardware video encoder is designed to be portable outdoors, embedded OS(embedded operating system), Its platform is based on BS configuration structure; management and configuration are done by this web-page in the long–distance without being supervised by human.

E9 Camera top SDI h264 hardware video codec support timing recording and network storage.

Technical Features

  • 3G/4G/WIFI/Wired network optional
  • Standard camera base holder and lithium battery
  • Resolution support 1920x1080P/1920x1080i/1280x720P/720*576i/720*576P/640*480i etc
  • Support H.265,H.264 Baseline profile,Main profile,High profile
  • Support stereo audio input for 2 channels, MP3,AAC,sampling frequency:32000,44100,48000 etc, Encoded audio bit rate:48K ,64K ,96K ,128K ,160K,192K ,256K
  • Support multiple computers to display background Settings page at the same time
  • Support CBR,VBR
  • Highest code rate 12Mbps
  • Automatic scene change detection technology, improve the coding effect
  • Every channel is inserted with de-interlacing scanning algorithm
  • E9 Camera top SDI h264 hardware video codec can use space pre-treatment and block filtering technology for moving scenes
  • E9 Camera top SDI h264 hardware video codec support wide area network remote management (WEB)
  • Support a variety of common platforms at home and abroad such as Wowza, FMS, youtube,facebook,NJ ,Darwin Server and so on


Topology diagram of the overall scheme


Product Advantages

  • SOC chip is even more powerful
  • Mini design is easy to carry
  • 1*1080P 30fps of image effect is more exquisite
  • Strong system stability
  • Low power supply design, can be battery powered, full can work for 5-6 hours
  • Multi-media platforms

Software configuration picture

Technical specification table

Product Parameter
Video parameterInput interface: 1*SDI Maximum 1080P

Resolution: 1920x1080P/1920x1080i/1280x720p/720*576i/720*576P /640*480i

Coded format:  H.264 Baseline profile H.264 Main profile H.264 High profile H.265 Main profile H.265 Main 10 profile

Coding resolution Main: 1920x1080P/1920x1080i/1280x720p/720*576i/720*576P /640*480i

Frame rate:1-30 fps adjustable

Maximum rate:12Mbps

Rate control :CBR,VBR

Audio parametersInput interface:1×3.5mm and HDMI Audio

Stereo Sampling rate:48K,44.1K,32K

Coded format:AAC,MP3

Audio bit rate:64Kb/s-384Kb/s

Network ParametersInternet:1*SIM card slot 3G/4G,Network type:LTE-FDD,TD-LTE

Lan interface: 1*100M/1000M RJ45 adaptive ethernet port,TS standard stream,dual-stream,ONVIF

Wireless interface:Dual frequency wifi module

Transport protocols :RTSP,RTMP,HTTP,HLS,UDP,unicast,multicast ONVIF:positive

File StorageMemory interface:TF Card

Recording format:MP4,TS,FLV,MOV,MKV,AVI

Basic parameterPower supply :DC 12V 2.4A

Power dissipation:<5W

Operating temperature:-20℃- +70℃

Operating humidity:<90%,No condensation

Size: 102*70*44 (mm)



Software function Basic function  WEB configuration,Parameter thermal update,Firmware upgrade,Network settings,Password management

Special superposition Logo,Watermark, subtitle, scrolling subtitle, Mosaic, timestamp

Resource management  Customize font, upload watermark Logo picture

Application Range

  • Digital TV Broadcasting System , IPTV & OTT system , Internet TV , Digital Signage Project , Remote Video Conference
    Video Monitoring , Live Streaming , Digital TV Broadcasting System , Digital TV Programs Transmission
    Hotel IPTV System , Head-end system of Digital TV branch network , CATV Broadcasting system
    Edge side of Digital TV backbone network
